Getting started

To try Copperline without installing anything, a WebAssembly build runs in the browser at copperline.dev/try; see The browser build for what it can do. The rest of this chapter covers the native desktop build.

Requirements¶

• Rust 1.93+ (stable). Tested with Rust 1.96.

• macOS, Linux, or Windows. There is no SDL2 dependency: video uses winit + pixels, audio uses cpal, and gamepads use the pure-Rust gilrs crate.

• A GPU backend for presentation: Metal on macOS, DX12 on Windows, and Vulkan on Linux (see Vulkan is required on Linux).

• Fedora build dependencies: sudo dnf install alsa-lib-devel systemd-devel gcc.

• A boot ROM. Copperline ships with the AROS open-source Kickstart replacement and boots it by default, so it runs out of the box with no ROM of your own. It also boots Kickstart 1.3, 2.05, and 3.1 (including the CDTV and CD32 extended ROMs) as well as DiagROM. Main Kickstart images must be exactly 512 KiB; CDTV/CD32 extended ROM sizes are covered in Top level.

Installing on macOS (Homebrew)¶

brew tap copperlinehq/copperline https://github.com/CopperlineHQ/Copperline
brew install copperline

The formula builds from source, so the binary is compiled locally and is not subject to macOS Gatekeeper quarantine: there is no Security & Privacy override to click through, unlike a downloaded prebuilt app. Use brew install --HEAD copperline to build the latest main instead of the most recent tagged release, then run copperline from the terminal.

For a no-compiler install, download Copperline-X.Y.Z-macos-universal.dmg from the releases page, open it, and drag Copperline.app onto the Applications shortcut. The app is a universal binary that runs natively on Apple Silicon and Intel, and bundles the AROS boot ROM, so it runs out of the box. The image is not code-signed or notarized, so on first launch Gatekeeper refuses to open it; right-click (or Control-click) the app and choose Open, then confirm. macOS remembers the choice. If it still refuses, clear the download quarantine with xattr -dr com.apple.quarantine /Applications/Copperline.app.

Installing on Linux¶

Two channels are provided.

Flatpak (recommended) works on any distribution and pulls in the GPU, audio and portal stack from the Freedesktop runtime, so there is nothing else to install:

flatpak install flathub dev.copperline.Copperline
flatpak run dev.copperline.Copperline

AppImage is a single self-contained file that needs no installation: download Copperline-X.Y.Z-<arch>.AppImage from the releases page, then:

chmod +x Copperline-*.AppImage
./Copperline-*.AppImage

Both bundle the AROS boot ROM, so they run out of the box. Packaging sources live in packaging/flatpak/ and packaging/appimage/.

Vulkan is required on Linux¶

The display is presented through wgpu’s Vulkan backend. The OpenGL fallback is disabled because wgpu initializes its EGL instance without a display handle and silently selects Mesa’s “surfaceless” platform, which cannot be paired with an on-screen window; adapter selection then fails. The symptom is the window flashing open and immediately exiting with:

ERROR copperline::video::window] pixels init failed: No suitable `wgpu::Adapter` found.

The fix is to provide a Vulkan driver. Any GPU from roughly Intel Skylake / 2015 onward ships a hardware Vulkan driver in mesa. Older hardware, a headless host, or a VM can use the software lavapipe ICD instead:

• Arch: sudo pacman -S vulkan-swrast

• Debian/Ubuntu: sudo apt install mesa-vulkan-drivers

• Fedora: sudo dnf install mesa-vulkan-drivers

Copperline renders entirely on the CPU and only asks the GPU to blit one framebuffer per frame, so software Vulkan is perfectly adequate. The Flatpak runtime already includes lavapipe, so the Flatpak needs no extra package. WGPU_BACKEND overrides backend selection if you need to force one for debugging.

Building¶

cargo build --release

The test suite needs no external assets:

cargo test                          # asset-free test suite
cargo test --release -- --ignored   # integration tests (need local ROMs/disks)

First boot¶

./target/release/copperline

With no arguments and no ./copperline.toml in the current directory, Copperline opens the configuration screen -- a launcher that lets you pick a machine, configure everything about it, load and save .toml configs, and press Run to boot. See Machine configuration screen for a full tour. The screen starts from the configuration saved with its Save default button, if you have saved one; otherwise from the built-in defaults: the A500 Rev 6A -- the most common and most-targeted Amiga: a 68000 at ~7.09 MHz, the ECS “Fatter” 8372A Agnus (1 MiB chip reach plus the software PAL/NTSC switch) with the original OCS 8362 Denise, 512 KiB chip RAM plus 512 KiB of trapdoor slow RAM, PAL, and the bundled AROS ROM (when no ROM is named, Copperline locates the AROS image that ships with it -- see Top level).

Copperline boots directly, skipping the configuration screen, whenever a machine is specified: a ./copperline.toml in the current directory, an explicit --config file, a ROM or override on the command line, or any headless/scripted run. Those runs also start from the saved default when neither --config nor ./copperline.toml names a machine; --factory ignores it (see Configuration reference). You can reopen the configuration screen at any time from the menu (see Machine configuration screen).

You can boot your own ROM with a positional argument, or point at a specific config file:

./target/release/copperline path/to/kickstart.rom
./target/release/copperline --config path/to/copperline.toml

The common machine knobs can also be set straight on the command line, without writing a config file at all -- the machine model, chipset, CPU (and its clock/FPU), and the chip/fast/slow RAM sizes:

./target/release/copperline --model A1200 --fast 8M KICK31.ROM

See Command-line overrides for the full list. copperline --help lists every flag, and copperline --version prints the release version.

A Kickstart 1.3 machine with no disk boots to the familiar insert-disk screen:

To boot a disk, add a floppy section to your config:

rom = "KICK13.ROM"

[floppy.df0]
path = "MyGame.adf"

Copperline accepts plain ADF images, gzip-compressed images, single file ZIP archives, DMS archives, UAE extended ADFs, and read-only IPF and SCP images. In a windowed session you can also just drag a disk image onto the window to insert it -- see Drag and drop.

Example configuration¶

copperline.example.toml in the repository root is a commented reference covering every option -- machine profiles, CPU/FPU, memory, chipset, floppy/HDD/CD images, and audio. Copy it to copperline.toml (or pass it with --config) and edit; it doubles as a worked example for the options described in Configuration reference.

./target/release/copperline --config copperline.example.toml

Logging¶

Copperline logs through the standard Rust log/env_logger machinery. RUST_LOG=debug (or trace) prints more detail from the CPU and MMIO layers, and is also how the headless debugger output is surfaced.

Crash reports¶

If Copperline itself crashes, it writes the crash message and a backtrace to copperline-crash.txt before exiting, so the details survive launches where nobody is watching the terminal (double-clicking copperline.exe on Windows, desktop launchers). The file is written next to the executable where possible, falling back to the current working directory and then the system temporary directory when that location is read-only (installed Homebrew/AppImage/Flatpak layouts); a run from a terminal prints the path chosen. The first crash of a run replaces the file, and any further crashes in the same run are appended to it, so it always covers the most recent session -- attach it when filing a bug report.
